Cutting edge technology: Power Factor 1, 96% efficiency, 3 level IGBT troubleshooting and testing in safety low voltage
Operates leading and lagging loads without derating
Generator compatibility with ramp up configurable in power and time delay with wide input frequency range
Lift compatibility to efficiently use reinjected energy from generative loads
THDi <3% for a minimized grid impact
Cold start (standard up to 20kVA, optional up to 80kVA)
UPS information, settings and log file easily downloadable on removable SD card from LCD to simplify service operations
Two strings of internal batteries up to 40kVA
Wide range of battery number per string from 32 to 40 LCD settable (26-40 for 10kVA))
Ready for Li-ion or other battery technology
Smart Battery Detection - immediate alarm once battery disconnected
Smart Battery Discharge - For Battery Discharge Test without extra loads and connections
Dual input and internal manual bypass
Parallelable up to 6 units, in power or redundancy, LCD settable
Separate or common batteries for parallel systems
Touch screen color LCD display for quick and user friendly operation
Wide communication offer as a standard: two com slots, RS232, USB, programmable dry contacts
Wrong phase sequence rotation protection
Flexible High Power charger
440mm wide fits into higher IP cabinets
Strong overload capacity (<200ms for > 150% overload) to garantee selectivity in the downstream installation
